With standard 6 mph motors, iLevel technology and advanced responsiveness, the Q6 Edge® 2.0 is engineered to meet the performance needs of the most active user.
ID/SKU:
$8,170.00 (incl. tax)
With standard 6 mph motors, iLevel technology and advanced responsiveness, the Q6 Edge® 2.0 is engineered to meet the performance needs of the most active user.
With standard 6 mph motors, iLevel technology and advanced responsiveness, the Q6 Edge® 2.0 is engineered to meet the performance needs of the most active user.
New standard 6 mph motors offer advanced performance, precise control and responsiveness via innovative singlestage gearbox
Bold new aesthetics
iLevel® option available with up to 10” of seat elevation (in 24 seconds) at walking speed (up to 3.5 mph)
iLevel® is retrofittable on the Q6 Edge® 2.0
TRU-Balance® 3 Seating
TRU-Comfort 2 Seating System
TRU-Balance® 3 10” Power Adjustable Seat with iLevel®
Q-Logic 2 EX Drive Controls
Trilogy vent tray 6
Compact vent tray 6
LED full lighting package
4” wide flat-free knobby extended traction tires
| Model | Q6 Edge 2.0 |
| Drive Wheels | 14″ Solid1 14″ Pneumatic2 |
| Caster Wheels | Front: 6″ Solid Rear: 6″ Solid |
| Maximum Speed4 | Up to 6 mph |
| Ground Clearance | 2.7″ at battery tray |
| Turning Radius5 | 20.5″ |
| Overall Length | 35.5 without foot riggings |
| Base Width | 24.4″ |
| Seating Sizes: Synergy/Static | TRU-Balance 3: Width 10″ – 22″ Depth 10″ – 22″ |
| Seating Sizes: Power Tilt | TRU-Balance 3: Width 12″ – 22″ Depth 12″ – 22″ |
| Seating Sizes: Lift and Tilt | TRU-Balance 3: Width 16″ – 22″ Depth 14″ – 22″ |
| Seat-to-Floor Heights: Synergy/Static8 | TRU-Balance 3: Width 15.9″ – 17.9″ |
| Seat-to-Floor Heights: Power Tilt8 | TRU-Balance 3: Width 17.5″ – 19.5″ |
| Seat-to-Floor Heights: Lift and Tilt8 | TRU-Balance 3: Width 17.5″ – 19.5″ |
| Available with Manual Tilt and Recline10 | Yes |
| Standard Battery Size6 | NF-22 (2) |
| Battery Weight14 | 38 lbs. each |
| Available Electronics12 | 75A Q-Logic 2 NE 75A Q-Logic 2 NE+ 100A Q-Logic 2 EX |
| Standard Charger | 8A Off-board |
| Motor Packages | 2-motor, 2-pole, Mid-Wheel 6® |
| Weight Capacity7 | 300 lbs. |
| Base Weight | 138.6 lbs. |
